[vip第4年] 指数:1
1）2指平行夹爪：mgp800系列、gp系列、gp400系列、gp200系列、gpp5000系列、 gpp1000系列
2）2指长行程平行夹爪：mgh8000系列、gh6000系列、gh7000系列
3）3心夹爪：mgp800系列、gd300系列、gpd5000系列
4）3指长行程定心夹爪：gd500系列
5）2指张角夹爪：gz1000系列、mgw800系列、 gg1000系列、 gk系列、gg4000系列
6）特殊夹爪：st系列、sch系列、gs系列、gsi系列、hm1000系列
zimmer automation总部位于德国，成立于1958年，主要设计生产液位控制器和阀门的系列产品，现已经成为许多厂商的凯发会员官网的合作伙伴。
厦门圣企机电设备有限公司是一家欧洲工业供应商。
线型钢制导轨 —
性能优异的导轨设计
钢 / 钢导轨能够持久保持高精度，坚固耐用，且使用寿命长，维护间隔高达 3 千万次抓取循环。欢迎选购此款商品并从中获益，同时提高您机器的经济性及过程安全性。
密封、防腐蚀 — 通用型抓手
几乎可用于所有环境条件，借助一个高达 ip67 密封等级的结构和标准化的防腐蚀工艺，您可将此机械夹爪应用于各类应用环境库存和生产成本。借此，您可避免在生产中频繁更换不同型号的机械夹爪，
从而降低库存和生产成本。
线型铝制导轨 — 替代方案
总的来说，与带 t 型槽滑轨的同类机械夹爪相比，钢 / 铝版本的导轨可为您提供优势更为明显的性能，与大多数齿形导向技术的效果不相上下。
系列特徵
（最多）3 千万次循环免维护 ip40ip64 ip67
电话 微信 黄先生:13774696989 厦门圣企机电设备有限公司 固话: 0592-6081295 qq : 2236798935 1519011860
耐腐蚀
磁场传感器
接近传感器
阻隔空气密封
耐高温
标准行程 / 弹簧式自锁/常闭
高夹持力 / 弹簧式自锁/常闭
标准行程 / 弹簧式自锁/常开
高夹持力 / 弹簧式自锁/常开
标准行程
高夹持力（最多）15 千万次循环免维护
线型钢制导轨
线型铝制导轨
订单号单边行程闭合抓取力张开抓取力
gpp5003n-00-a2.5 [mm] 140 [n] 150 [n]
gpp5003nc-00-a2.5 [mm] 195 [n]
gpp5003no-00-a2.5 [mm] 215 [n]
gpp5003n-20-a2.5 [mm] 140 [n] 150 [n]
gpp5003nc-20-a2.5 [mm] 205 [n]
gpp5003no-20-a2.5 [mm] 215 [n]
gpp5003n-21-a2.5 [mm] 140 [n] 150 [n]
gpp5003nc-21-a2.5 [mm] 205 [n]
gpp5003no-21-a2.5 [mm] 215 [n]
gpp5003n-24-a2.5 [mm] 140 [n] 150 [n]
gpp5003nc-24-a2.5 [mm] 205 [n]
gpp5003no-24-a2.5 [mm] 215 [n]
gpp5003n-al-a2.5 [mm] 140 [n] 150 [n]
gpp5003nc-al-a2.5 [mm] 195 [n]
gpp5003no-al-a2.5 [mm] 205 [n]
安装尺寸: gpp5004
订单号单边行程闭合抓取力张开抓取力
gpp5004n-00-a4 [mm]200 [n]215 [n]
gpp5004nc-00-a4 [mm]280 [n]
gpp5004no-00-a4 [mm]295 [n]
gpp5004s-00-a2 [mm]440 [n]470 [n]
gpp5004sc-00-a2 [mm]600 [n]
gpp5004so-00-a2 [mm]630 [n]
gpp5004n-20-a4 [mm]200 [n]215 [n]
gpp5004nc-20-a4 [mm]280 [n]
gpp5004no-20-a4 [mm]295 [n]
gpp5004s-20-a2 [mm]440 [n]470 [n]
gpp5004sc-20-a2 [mm]600 [n]
gpp5004so-20-a2 [mm]630 [n]
gpp5004n-21-a4 [mm]200 [n]215 [n]
gpp5004nc-21-a4 [mm]280 [n]
gpp5004no-21-a4 [mm]295 [n]
gpp5004s-21-a2 [mm]440 [n]470 [n]
gpp5004sc-21-a2 [mm]600 [n]
gpp5004so-21-a2 [mm]630 [n]
gpp5004n-24-a4 [mm]200 [n]215 [n]
gpp5004nc-24-a4 [mm]280 [n]
gpp5004no-24-a4 [mm]295 [n]
gpp5004s-24-a2 [mm]440 [n]470 [n]
gpp5004sc-24-a2 [mm]600 [n]
gpp5004so-24-a2 [mm]630 [n]
gpp5004n-al-a4 [mm]200 [n]215 [n]
gpp5004nc-al-a4 [mm]280 [n]
gpp5004no-al-a4 [mm]295 [n]
安装尺寸: gpp5006
订单号单边行程闭合抓取力张开抓取力
gpp5006n-00-a6 [mm]330 [n]360 [n]
gpp5006nc-00-a6 [mm]455 [n]
gpp5006no-00-a6 [mm]485 [n]
gpp5006s-00-a3 [mm]740 [n]800 [n]
gpp5006sc-00-a3 [mm]1020 [n]
gpp5006so-00-a3 [mm]1080 [n]
gpp5006n-20-a6 [mm]330 [n]360 [n]
gpp5006nc-20-a6 [mm]455 [n]
gpp5006no-20-a6 [mm]485 [n]
gpp5006s-20-a3 [mm]740 [n]800 [n]
gpp5006sc-20-a3 [mm]1020 [n]
gpp5006n-21-a6 [mm]330 [n]360 [n]
gpp5006nc-21-a6 [mm]455 [n]
gpp5006no-21-a6 [mm]485 [n]
gpp5006s-21-a3 [mm]740 [n]800 [n]
gpp5006sc-21-a3 [mm]1020 [n]
gpp5006so-21-a3 [mm]1080 [n]
gpp5006n-24-a6 [mm]330 [n]360 [n]
gpp5006nc-24-a6 [mm]455 [n]
gpp5006no-24-a6 [mm]485 [n]
gpp5006s-24-a3 [mm]740 [n]800 [n]
gpp5006sc-24-a3 [mm]1020 [n]
gpp5006so-24-a3 [mm]1080 [n]
gpp5006n-al-a6 [mm]330 [n]360 [n]
gpp5006nc-al-a6 [mm]455 [n]
gpp5006no-al-a6 [mm]485 [n]
安装尺寸: gpp5008
订单号单边行程闭合抓取力张开抓取力
gpp5008n-00-a8 [mm]520 [n]560 [n]
gpp5008nc-00-a8 [mm]710 [n]
gpp5008no-00-a8 [mm]750 [n]
gpp5008s-00-a4 [mm]1150 [n]1240 [n]
gpp5008sc-00-a4 [mm]1580 [n]
gpp5008so-00-a4 [mm]1670 [n]
gpp5008n-20-a8 [mm]520 [n]560 [n]
gpp5008nc-20-a8 [mm]710 [n]
gpp5008no-20-a8 [mm]750 [n]
gpp5008s-20-a4 [mm]1150 [n]1240 [n]
gpp5008sc-20-a4 [mm]1580 [n]
gpp5008so-20-a4 [mm]1670 [n]
gpp5008n-21-a8 [mm]520 [n]560 [n]
gpp5008nc-21-a8 [mm]710 [n]
gpp5008no-21-a8 [mm]750 [n]
gpp5008s-21-a4 [mm]1150 [n]1240 [n]
gpp5008sc-21-a4 [mm]1580 [n]
gpp5008so-21-a4 [mm]1670 [n]
gpp5008n-24-a8 [mm]520 [n]560 [n]
gpp5008nc-24-a8 [mm]710 [n]
gpp5008no-24-a8 [mm]750 [n]
gpp5008s-24-a4 [mm]1150 [n]1240 [n]
gpp5008sc-24-a4 [mm]1580 [n]
gpp5008so-24-a4 [mm]1670 [n]
gpp5008n-al-a8 [mm]520 [n]560 [n]
gpp5008nc-al-a8 [mm]710 [n]
gpp5008no-al-a8 [mm]750 [n]
安装尺寸: gpp5010
订单号单边行程闭合抓取力张开抓取力
gpp5010n-00-a10 [mm]885 [n]945 [n]
gpp5010nc-00-a10 [mm]1260 [n]
gpp5010no-00-a10 [mm]1320 [n]
gpp5010s-00-a5 [mm]1940 [n]2080 [n]
gpp5010sc-00-a5 [mm]2750 [n]
gpp5010so-00-a5 [mm]2890 [n]
gpp5010n-20-a10 [mm]885 [n]945 [n]
gpp5010nc-20-a10 [mm]1260 [n]
gpp5010no-20-a10 [mm]1320 [n]
gpp5010s-20-a5 [mm]1940 [n]2080 [n]
gpp5010sc-20-a5 [mm]2750 [n]
gpp5010so-20-a5 [mm]2890 [n]
gpp5010n-21-a10 [mm]885 [n]945 [n]
gpp5010nc-21-a10 [mm]1260 [n]
gpp5010no-21-a10 [mm]1320 [n]
gpp5010s-21-a5 [mm]1940 [n]2080 [n]
gpp5010sc-21-a5 [mm]2750 [n]
gpp5010so-21-a5 [mm]2890 [n]
gpp5010n-24-a10 [mm]885 [n]945 [n]
gpp5010nc-24-a10 [mm]1260 [n]
gpp5010no-24-a10 [mm]1320 [n]
gpp5010s-24-a5 [mm]1940 [n]2080 [n]
gpp5010sc-24-a5 [mm]2750 [n]
gpp5010so-24-a5 [mm]2890 [n]
gpp5010n-al-a10 [mm]885 [n]945 [n]
gpp5010nc-al-a10 [mm]1260 [n]
gpp5010no-al-a10 [mm]1320 [n]
安装尺寸: gpp5013
订单号单边行程闭合抓取力张开抓取力
gpp5013n-00-a13 [mm]1410 [n]1490 [n]
gpp5013nc-00-a13 [mm]1920 [n]
gpp5013no-00-a13 [mm]1860 [n]
gpp5013s-00-a6 [mm]3100 [n]3280 [n]
gpp5013sc-00-a6 [mm]4220 [n]
gpp5013so-00-a6 [mm]4400 [n]
gpp5013n-20-a13 [mm]1410 [n]1490 [n]
gpp5013nc-20-a13 [mm]1920 [n]
gpp5013no-20-a13 [mm]1860 [n]
gpp5013s-20-a6 [mm]3100 [n]3280 [n]
gpp5013sc-20-a6 [mm]4220 [n]
gpp5013so-20-a6 [mm]4400 [n]
gpp5013n-21-a13 [mm]1410 [n]1490 [n]
gpp5013nc-21-a13 [mm]1920 [n]
gpp5013no-21-a13 [mm]1860 [n]
gpp5013s-21-a6 [mm]3100 [n]3280 [n]
gpp5013sc-21-a6 [mm]4220 [n]
gpp5013so-21-a6 [mm]4400 [n]
gpp5013n-24-a13 [mm]1410 [n]1490 [n]
gpp5013nc-24-a13 [mm]1920 [n]
gpp5013no-24-a13 [mm]1860 [n]
gpp5013s-24-a6 [mm]3100 [n]3280 [n]
gpp5013sc-24-a6 [mm]4220 [n]
gpp5013so-24-a6 [mm]4400 [n]
gpp5013n-al-a13 [mm]1410 [n]1490 [n]
gpp5013nc-al-a13 [mm]1920 [n]
gpp5013no-al-a13 [mm]1860 [n]
安装尺寸: gpp5016
订单号单边行程闭合抓取力张开抓取力
gpp5016nc-00-a16 [mm]2860 [n]
gpp5016no-00-a16 [mm]2990 [n]
gpp5016s-00-a8 [mm]4610 [n]4900 [n]
gpp5016sc-00-a8 [mm]6310 [n]
gpp5016so-00-a8 [mm]6600 [n]
gpp5016n-20-a16 [mm]2090 [n]2200 [n]
gpp5016nc-20-a16 [mm]2860 [n]
gpp5016no-20-a16 [mm]2990 [n]
gpp5016s-20-a8 [mm]4610 [n]4900 [n]
gpp5016sc-20-a8 [mm]6310 [n]
gpp5016so-20-a8 [mm]6600 [n]
gpp5016n-21-a16 [mm]2090 [n]2220 [n]
gpp5016nc-21-a16 [mm]2860 [n]
gpp5016no-21-a16 [mm]2990 [n]
gpp5016s-21-a8 [mm]4610 [n]4900 [n]
gpp5016sc-21-a8 [mm]6310 [n]
gpp5016so-21-a8 [mm]6600 [n]
gpp5016n-24-a16 [mm]2090 [n]2200 [n]
gpp5016nc-24-a16 [mm]2860 [n]
gpp5016no-24-a16 [mm]2990 [n]
gpp5016s-24-a8 [mm]4610 [n]4900 [n]
gpp5016sc-24-a8 [mm]6310 [n]
gpp5016so-24-a8 [mm]6600 [n]
gpp5016n-al-a16 [mm]2090 [n]2220 [n]
gpp5016nc-al-a16 [mm]2860 [n]
gpp5016no-al-a16 [mm]2990 [n]
安装尺寸: gpp5025
订单号单边行程闭合抓取力张开抓取力
gpp5025n-00-a25 [mm]3280 [n]3490 [n]
gpp5025nc-00-a25 [mm]4510 [n]
gpp5025no-00-a25 [mm]4710 [n]
gpp5025s-00-a14 [mm]6360 [n]6760 [n]
gpp5025sc-00-a14 [mm]8730 [n]
gpp5025so-00-a14 [mm]9130 [n]
gpp5025n-20-a25 [mm]3280 [n]3490 [n]
gpp5025nc-20-a25 [mm]4510 [n]
gpp5025no-20-a25 [mm]4710 [n]
gpp5025s-20-a14 [mm]6360 [n]6760 [n]
gpp5025sc-20-a14 [mm]8730 [n]
gpp5025so-20-a14 [mm]9130 [n]
gpp5025n-21-a25 [mm]3280 [n]3490 [n]
gpp5025nc-21-a25 [mm]4510 [n]
gpp5025no-21-a25 [mm]4710 [n]
gpp5025s-21-a14 [mm]6360 [n]6760 [n]
gpp5025sc-21-a14 [mm]8730 [n]
gpp5025so-21-a14 [mm]9130 [n]
gpp5025n-24-a25 [mm]3280 [n]3490 [n]
gpp5025nc-24-a25 [mm]4510 [n]
gpp5025no-24-a25 [mm]4710 [n]
gpp5025s-24-a14 [mm]6360 [n]6760 [n]
gpp5025sc-24-a14 [mm]8730 [n]
gpp5025so-24-a14 [mm]9130 [n]
安装尺寸: gpp5030
订单号单边行程闭合抓取力张开抓取力
gpp5030n-00-a30 [mm]5000 [n]5210 [n]
gpp5030nc-00-a30 [mm]6850 [n]
gpp5030no-00-a30 [mm]7060 [n]
gpp5030s-00-a17 [mm]9600 [n]9990 [n]
gpp5030sc-00-a17 [mm]13160 [n]
gpp5030so-00-a17 [mm]13550 [n]
gpp5030n-20-a30 [mm]5000 [n]5210 [n]
gpp5030nc-20-a30 [mm]6850 [n]
gpp5030no-20-a30 [mm]7060 [n]
gpp5030s-20-a17 [mm]9600 [n]9990 [n]
gpp5030sc-20-a17 [mm]13160 [n]
gpp5030so-20-a17 [mm]13550 [n]
gpp5030n-21-a30 [mm]5000 [n]5210 [n]
gpp5030nc-21-a30 [mm]6850 [n]
gpp5030no-21-a30 [mm]7060 [n]
gpp5030s-21-a17 [mm]9600 [n]9990 [n]
gpp5030sc-21-a17 [mm]13160 [n]
gpp5030so-21-a17 [mm]13550 [n]
gpp5030n-24-a30 [mm]5000 [n]5210 [n]
gpp5030nc-24-a30 [mm]6850 [n]
gpp5030no-24-a30 [mm]7060 [n]
gpp5030s-24-a17 [mm]9600 [n]9990 [n]
gpp5030sc-24-a17 [mm]13160 [n]
gpp5030so-24-a17 [mm]13550 [n]
安装尺寸: gpp5035
订单号单边行程闭合抓取力张开抓取力
gpp5035n-00-a35 [mm]6100 [n]6300 [n]
gpp5035nc-00-a35 [mm]8000 [n]
gpp5035no-00-a35 [mm]8200 [n]
gpp5035s-00-a20 [mm]11700 [n]12100 [n]
gpp5035sc-00-a20 [mm]15500 [n]
gpp5035so-00-a20 [mm]15900 [n]
gpp5035n-20-a35 [mm]6100 [n]6300 [n]
gpp5035no-20-a35 [mm]8200 [n]
gpp5035s-20-a20 [mm]11700 [n]12100 [n]
gpp5035sc-20-a20 [mm]15500 [n]
gpp5035so-20-a20 [mm]15900 [n]
gpp5035n-21-a35 [mm]6100 [n]6300 [n]
gpp5035nc-21-a35 [mm]8000 [n]
gpp5035no-21-a35 [mm]8200 [n]
gpp5035s-21-a20 [mm]11700 [n]12100 [n]
gpp5035sc-21-a20 [mm]15500 [n]
gpp5035so-21-a20 [mm]15900 [n]
gpp5035n-24-a35 [mm]6100 [n]6300 [n]
gpp5035nc-24-a35 [mm]8000 [n]
gpp5035no-24-a35 [mm]8200 [n]
gpp5035s-24-a20 [mm]11700 [n]12100 [n]
gpp5035sc-24-a20 [mm]15500 [n]
gpp5035so-24-a20 [mm]15900 [n]
安装尺寸: gpp5045
订单号单边行程闭合抓取力张开抓取力
gpp5045n-00-a45 [mm]10200 [n]10700 [n]
gpp5045nc-00-a45 [mm]13700 [n]
gpp5045no-00-a45 [mm]14200 [n]
gpp5045s-00-a26 [mm]19400 [n]20300 [n]
gpp5045sc-00-a26 [mm]26050 [n]
gpp5045so-00-a26 [mm]26950 [n]
gpp5045n-20-a45 [mm]10200 [n]10700 [n]
gpp5045nc-20-a45 [mm]13700 [n]
gpp5045no-20-a45 [mm]14200 [n]
gpp5045s-20-a26 [mm]19400 [n]20300 [n]
gpp5045sc-20-a26 [mm]26050 [n]
gpp5045so-20-a26 [mm]26950 [n]
gpp5045n-21-a45 [mm]10200 [n]10700 [n]
gpp5045nc-21-a45 [mm]13700 [n]
gpp5045no-21-a45 [mm]14200 [n]
gpp5045s-21-a26 [mm]19400 [n]20300 [n]
gpp5045sc-21-a26 [mm]26050 [n]
gpp5045so-21-a26 [mm]26950 [n]
gpp5045n-24-a45 [mm]10200 [n]10700 [n]
gpp5045nc-24-a45 [mm]13700 [n]
gpp5045no-24-a45 [mm]14200 [n]
gpp5045s-24-a26 [mm]19400 [n]20300 [n]
gpp5045sc-24-a26 [mm]26050 [n]
gpp5045so-24-a26 [mm]26950 [n]
